New Kubota BX1880 Tractor

Description

New Kubota BX1880 Tractor



Smaller than a full-size tractor and easier to operate, the sub-compact BX80 Series has the power and versatility to take on your toughest gardening, landscaping, and property maintenance jobs. A fuel efficient 3- cylinder diesel engine provides plenty of power to haul, climb, and pull your way through even the most challenging tasks.

Specs

Model
BX1880

Engine
Type Liquid-cooled, 3-cylinder diesel
Model Kubota D722
Engine gross HP at 3200 rpm HP (kW) 18.0 (13.4)
PTO horsepower at 3200 rpm HP (kW) 13.7 (10.2)
Displacement 43.9 (719)
Fuel tank capacity gal. (l) 6.6 (25)

Drive train
Transmission HST, High-Low gear shift ( 2 forward / reverse )
Drive method 4WD
Brakes Wet disc
PTO Live independent PTO (with hydraulic clutch)
Rear PTO STD (540rpm)
Mid-PTO  STD (2500rpm)

Hydraulics
Pump output gpm (l/min.) 6.2 (23.5)
3-Point hitch SAE Category I
Lift capacity @ 24″ behind pin lbs. (kg) 680 (310)
Steering Hydraulic power steering

Tire size
Front Turf/Bar/Industrial 16×7.5– 8 / 16×7.5– 8 / N.A.
Rear Turf/Bar/Industrial 24×12–12 / 24×12–12 / N.A.

Traveling speeds at rated engine rpm (Turf)
Forward mph (km/h) 0 – 7.8 ( 0 – 12.5)
Reverse mph (km/h) 0 – 5.9 ( 0 – 9.5)

Dimensions
Length with 3-point hitch in. (mm) 95.5 (2425)
Width in. (mm) 44.1 (1120)
Height with ROPS in. (mm) 81.9 (2080)
Wheelbase in. (mm) 55.1 (1400)
Ground clearance (front axle) in. (mm) 8.3 (210)

Tread
Front in. (mm) 36.6 (930)
Rear in. (mm) 32.2 (820)
Turning radius (w/o brake) feet (m) 7.5 (2.3)
Tractor weight (w/ROPS) lbs. (kg)  1336 (606)

Specifications

  • Registration date: 2018
  • Condition: New
  • Fuel: Diesel
  • Drive: 4WD
